Albina recently rolled various material for the eagle feather-inspired roof at the American Indian Hall at Montana State University in Bozeman, Montana. ThinkOne Construction Management designed a barrel-vaulted, curved, standing beam roof in the shape and color of an eagle feather. Metal roofing was specified to ensure durability and to create a non-penetrating attachment point for solar panels. The project was featured on page 37 of the October/November Issue of Metal Architecture.

TS 14" X 4" X .375" WALL A500 GR B-2 pcs rolled the easy way to a 27’ -8” radius

6" X 6" X 5/16" ANGLE A36-7 pcs rolled leg out to a 92’-0” radius

4" X 4" X ½" ANGLE A36-2 pcs rolled leg out to a 107’-3” radius

Photo Credit: Jacob Teats

We also rolled the materials for the spiral staircase on this project.

MC12 X 10.6# A36

5 pcs rolled flanges out to a 67’-0” radius

4 pcs spiral rolled flanges out to a 67’-0” radius

5 pcs rolled flanges in to radii ranging from 57’-5” - 67’-5” radius

4 pcs spiral rolled flanges in to a 63’-0” radius

2" X 2" X ¼" ANGLE A36

1 pc rolled leg out to a 67’-5” radius

1 pc rolled leg in to a 67’-10” radius

Photo Credit: Jacob Teats

Photo Credit: Linda Ulery

The Awards just keep on coming! The National Steel Bridge Alliance has awarded the Williams Creek Shoup Bridge in Salem, Idaho a Merit Award in the Medium Span bridges category. Albina was happy to be a part of the project and provided 145,000# of bent structural steel and HSS including:

W18 X 234# A992
4 lengths x 100 ft- bent the easy way to a 179 ft radius
2 lengths x 75 ft- bent the easy way to a 179 ft radius

TS 8" X 8" X .375" WALL A500 GR B
8 lengths x 53 ft: bent to a 304 ft radius.

Photo Credit: Don Perkins (Photos 2 & 3)

The AISC website has detailed information about the project, the design, the construction, erection, and more.

Albina Co., Inc., was lucky enough to be the bender/roller for a beautiful spiral staircase that graces the lobby of one of the major tech companies headquartered in San Jose, California. Albina bent the following materials for the project:

Tube Steel 3" X 3" X .375" WALL A500 GR B
Channel C15 X 40# A572-50
3/8" THICK X 24" WIDE CORTEN PLATE
¼" THICK X 77¾" WIDE CORTEN PLATE
¼" THICK X 29½" WIDE CORTEN PLATE

The Inside stringer for the staircase was rolled to a 26’-11” radius and the outside stringer was rolled to a 32’-3” radius.

The Pacific Fleet Submarine Memorial Association operates USS Bowfin Submarine Museum & Park. It is the most visited submarine museum in the world. The museum aims to educate the public and honor veterans in a way that does justice to the brave men and women of the Silent Service. The USS Bowfin Submarine Museum & Park is undergoing a major improvement project and renaming itself The Pacific Fleet Submarine Museum at Pearl Harbor. In the video you can see one of the submarines in the bay. The ring resembles the hull of a submarine and will be featured as visitors enter the park. For more information and project renderings, click here. Albina bent the following materials for the project:

22,000# of rolled steel:
3 x 40 ft: TS 12" X 6" X .625" WALL A500 GR B. Net 3 pcs rolled the Easy Way to a 21 ft radius.
2 x 35 ft: TS 10" X 4" X .375" WALL A500 GR B. Net 2 pcs rolled the Easy Way to a 42 ft radius.
TS 12" X 4" X .375" WALL A500 GR B. Net 18 pcs rolled. Some rolled the Hard way and others rolled the Easy way. Radii ranging from 13 ft to 231 ft.
TS 10" X 6" X .375" WALL A500 GR B. Net 3 pcs rolled the Easy Way to a 24 ft radius.
W14 X 34# A992. Net 2 pcs rolled the Easy Way to a 24 ft radius.
4" X 4" X 3/8" ANGLE A36. Net 4 pcs rolled the Leg Out to a 24 ft radius.

Check back soon for final installation pictures! They are going to be spectacular!

Albina recently supplied 40,000# of bent steel for Kelli McGregor Square Mixed Use Development located outside Coors Field in Denver, Colorado. We bent the following materials.

TS 12" X 8" X .500" WALL A500 GR C
11 pcs bent the easy way
Various radii: 73 ft – 90 ft

TS 12" X 6" X .500" WALL A500 GR C
12 pcs bent the easy way
Various radii: 62 ft – 73 ft

To read more about the project and see renderings of what the final area will look like please read the article in Denver's Mile High Magazine.

Albina recently bent 37,000# of HSS for the Living Waters Express Car Wash in Aurora, Colorado. The concept for the Living Water Express Car Wash was to design a building that resembled flowing water. For more info on the project go to https://linktr.ee/AlbinaCoInc . To help our customer achieve their goals, we bent various materials including:TS 10" X 2" X .250" WALL A500 GR B- 10 pcs bent the hard way
TS 10" X 8" X .250" WALL A500 GR B- 6 pcs bent the hard way
TS 10" X 8" X .375" WALL A500 GR B- 6 pcs bent the hard way
TS 10" X 8" X .313" WALL A500 GR B- 4 pcs bent the hard way
TS 8" X 8" X .250" WALL A500 GR B- 4 pcs bent
3" X 3" X ¼" ANGLE A36- 36 pcs bent leg in
TS 8" X 2" X .250" WALL A500 GR B- 2 pcs bent the easy way

Thanks to Viva Railings LLC (Photo credit & Glass/Railing Fabricator) we have received some final installation pictures of the circular staircase at the "Trinity Complex", home to American Airlines Headquarters in Fort Worth, Texas. We spiral bent Tube Steel 16″ X 16″ X .625″ WALL A500 GR B bent down to a an 18 foot radius, using our induction heating process to create the spiral stringers for the staircase. In addition to the 16″ square, we produced another set of spiral stringers consisting of Tube Steel 14″ x 6″ x .625″ wall REALLY tight, exposed and bent to a 5′-6″ radius on a 45° pitch. These are the type of bends that ONLY Albina can do! The 1.7 million-square-foot complex, dubbed the “Trinity complex,” consists of four seven-story buildings. It cost nearly $300 million to build and houses over 6,500 employees. There were 10 tower cranes on the project and more than 1,000 construction workers on-site during the peak of the project.

Albina bent 40,000# of steel for the Freyer-Newman Center, home to Denvers’ Botanical Gardens. Albina bent 60 pieces of W8 X 31# A992 the hard way to a full scale layout. We also bent Tube Steel 8" X 6" X .500" WALL A500 GR B the hard way and MC8 X 20# A36 the hard way. The Freyer - Newman Center is a LEED GOLD building, designed by Denver’s Davis Partnership Architects. The Center will house six classrooms; four galleries; new herbaria for vascular plants, mushrooms and slime molds; laboratories; a new library and a coffee shop, and is slated for completion this spring. Final install pictures coming soon!

Albina provided 109,000# of bent steel for the Eli Lilly San Diego Biotech Center in La Jolla, CA. Eli Lilly doubled the size of its research facility to 300,000 square feet during this project. Materials included: 8″ X 8″ X 5/8″ ANGLE A36- half of the parts rolled leg in and half of the parts rolled leg out. Tube Steel 8″ X 8″ X .500″ WALL A500 GR B 8 5/8″ OD X .625″ WALL A500B Wide Flange W16 X 57# A992- Split into WT8 and rolled some parts stem in and rolled some parts stem out. Wide Flange W24 X 103# A992- DOUBLE split to a finished height of 8¼” tall. Albina then rolled some parts stem in and other stem out.

Albina bent 45,000 lbs. of steel for the Chase Center- Home of the Golden State Warriors. Materials bent included Tube Steel 2" X 2" X .250" WALL A500 GR B, Tube Steel 14" X 14" X .500" WALL A500 GR B, Tube Steel 3" X 3" X .375" WALL A500 GR B, and Tube Steel 12" X 12" X .500" WALL A500 GR all bent to a 270 ft radius. The stadium is located in the Mission Bay area of San Francisco.
