San Diego Zoo Habitats, Bridges and Buildings Showcase Curved Steel at It's Best!
San Diego Zoo Habitats, Bridges and Buildings Showcase Curved Steel at It's Best!

We have had the pleasure of providing many bent steel pieces for some fabulous projects at the San Diego Zoo including the Hummingbird Habitat, Komodo Kingdom, the Invert Building, the ZPA Catering Building, the Food Services Building, the Raintree Restroom and many more exhibits throughout both the Children’s zoo and the main part of the zoo.

Basher Bridge

24 lengths x 48 ft long of 16" OD x .625" wall

Some rolled to a 20 ft radius.

Some rolled to a 50 ft radius.

Some rolled to a 350 ft radius.

Basher Bridge San Diego Zoo

Basher Bridge San Diego Zoo

Hummingbird Building

7 Lengths TS 8” x 4” x .375” Wall A500 GR B rolled Hard Way on various Radii from 24’-8” down to 6’-2”

9 Lengths TS 18 x 6” x .500” Wall A500 GR B rolled Easy Way on various Radii from 30’-11” down to 6’-0”

Hummingbird Habitat San Diego Zoo

Komodo Exhibit

8 Lengths WT5 X 22.5# A992 Split from W10 x 45# Beam and rolled stem up to various Radii from 46’-2” down to 6’-2”

1 Length TS 3” x 3” x .313” Wall A500 GR B rolled to 13’-4” Radii

2 Lengths 6” OD X .500” Wall A500B rolled to various Radii

3 Lengths 6” OD X .375” Wall A500B rolled to various Radii

1 Length TS 12” x 8” x .500” Wall A500B Induction formed easy way to 4’-4” Radii

3 Lengths TS 3” x 3” x .313” Wall A500B rolled on various Radii from 13’-4” down to 5’-0”

7 Lengths TS 3” x 3” x .375” Wall A500B rolled on various Radii from 7’-10” down to 2’-3”

7 Lengths TS 8” x 4” x .375” Wall A500b rolled hard way on various Radii from 51’-6” down to 6’-8”

6 Lengths TS 18” x 6” x .500” Wall A500B rolled easy way on various Radii from 51’-4” down to 6’-6”

10 Lengths TS 6” x 6” x .500” Wall A500B rolled on various Radii from 56’-0” down to 7’-11”

10 Lengths C9 x 13.4# A36 rolled Flanges out and Flanges in on various Radii from 56’-0” down to 7’-11”

6 Lengths TS 12” x 6” x .500” Wall A500 GR B rolled hard way to various Radii from 46’-4” down to 6’-4”

10 Lengths PL ½" THICK X 12" WIDE A36 rolled hard way to various Radii from 46’-9” down to 5’-9”

Komodo Kingdom San Diego Zoo Curved Steel Roof

Invert Building

7 Lengths TS 10” x 8” x .500” Wall A500 GR B rolled Hard Way on 10’-0” Radius

1 Length C12 x 20.7# A36 rolled flanges out to 17’-1” and 11’-10” Radii

2 Lengths 4” x 4” x 3/8” Angle T304 S/S Rolled Leg in and Leg out to 7’-1” and 7’-3” Radii

1 Length 4” x 3” x 3/8” Angle T304 S/S Rolled Leg out to 3’-11” and 9’-4” Radii

Temperature Exhibit

28 Lengths 5/8” Solid Round A36 Rolled to various Radii from 70’-3” down to 3’-11”

9 Lengths TS 8” x 6” x .375” Wall A500B rolled Easy Way to various Radii from 70’-3” down to 3’-11”

9 Lengths C9 x 13.4# A36 Rolled Flanges in and Flanges out to various Radii from 70’-3” down to 3’-11”

ZPA Catering Building

3 Lengths TS 5” x 4” x .375” Wall A500 GR B rolled easy way to various Radii from 40’-7” down to 11’-7”

3 Lengths C9 x 13.4# A36 rolled flanges out to various Radii from 40’-7” down to 11’-7”

3 Lengths TS 6” x 4” x .25” Wall A500 GR B rolled easy way on various Radii from 40’-7” down to 11’-7”

Food Services Building

6 Lengths TS 6” x 4” x .250” Wall A500B rolled easy way to various Radii from 8’-0” down to 4’-10”

6 Lengths C9 x 13.4# A36 Rolled flanges in and flanges out to various Radii from 8’-0” down to 4’-10”

Raintree Restroom

8 Lengths TS 16” x 12” x .500” Wall A500B rolled hard way to 999’-4” Radii

Curved Steel Koala Exhibit San Diego Zoo

Face Painting Curved Steel Roof San Diego Zoo

San Diego Children's Zoo

San Diego Children's Zoo

San Diego Children's Zoo

San Diego Children's Zoo

Elephant Exhibit at the San Diego Zoo

Exhibit at the San Diego Zoo

Exhibit at the San Diego Zoo

Curved Steel Facades Add Modern Touch to Newly Redesigned Bridgeport Village Outdoor Mall
Curved Steel Facades Add Modern Touch to Newly Redesigned Bridgeport Village Outdoor Mall

Bridgeport Village, an upscale outdoor mall in Tigard, Oregon recently underwent a $35 million dollar modernization and now features covered seating areas, a central courtyard area with new landscaping, a performance stage, updated building facades and about 20 new storefronts. Albina Co., Inc. was instrumental in helping the developers update the storefronts and bent various materials including:


2 lengths x 40 ft: W10 X 22# A992
Albina to roll all possible from each length (the easy way) to a 40’-4” centerline radius.

4 pcs of 3” X 3” X ¼” ANGLE A36
Albina to roll all possible from each length (leg in) to a 42’-7” outside radius.

3 lengths x 20 ft: 3” X 2” X ¼” ANGLE A36
Albina to roll all possible from each length (3” Leg in) to a 59’-1” outside radius.

3 lengths x 20 ft: 6” X 4” X 5/16” ANGLE A36
Albina to roll all possible from each length (4” Leg in) to a 59’-1” outside radius.

5 lengths x 20 ft: C10 X 20# A36
Albina to roll all possible from each length (flanges out) to radii ranging from 52’-7” – 59’-1”.

3 lengths x 20 ft: 3” X 2” X ¼” ANGLE A36
Albina to roll all possible from each length (2” Leg in) to a 58’-11” outside radius.

2 lengths x 20 ft: 3” X 3” X ¼” ANGLE A36
Albina to roll all possible from each length (Leg out) to a 52’-7” inside radius.

Bridgeport Village Curved Steel Storefront

Bridgeport Village Curved Steel Storefront

Bridgeport Village Curved Steel Storefront

Red Electric Curved Steel Trail Bridge Provides Pedestrians and Cyclists a Car-Free Scenic Route into SW Portland
Red Electric Curved Steel Trail Bridge Provides Pedestrians and Cyclists a Car-Free Scenic Route into SW Portland

Albina bent 10 lengths of 60-65 foot spans of wide flange W36 X 135# A709-50W the easy way to a radius range of 95 ft – 229 ft, depending on the length and section of the bridge. The Red Electric Bridge, located in Southwest Portland, provides pedestrians and cyclists with a direct, car-free link to the main streets of the area through a forested gulch.

Red Electric Pedestrian Trail Bridge Beams

Red Electric Pedestrian Trail Bridge SW Portland

Red Electric Pedestrian Trail Bridge

Steel Solutions Help Launch Seattle's Space Needle Into the Future
Steel Solutions Help Launch Seattle's Space Needle Into the Future

Albina Co. Inc. bent the spiral staircases at the newly renovated Space Needle in Seattle, Washington. The Space Needle's rotating glass floor, dubbed "The Loupe", is located just below the open-air observation deck and Albina Co., Inc. was the steel bender/roller for the custom spiral staircases connecting the two areas. The stair centilevers off concealed supports, so the staircase appears to float above the glass floor below thus creating a very unique experience for the visitors.

Albina Co., Inc. bent 1" thick x 13 ¼" wide A572 GR 50 to yield three 180" pieces and three 144" pieces of rolled plate and 1" thick x 10-13/16" wide A572 GR 50 to yield one 80" piece of rolled plate. We also bent tube steel 10" x 6" x .625" WALL A500 GR B to a 11’ 6” inside plan view radius (the easy way).

More detailed information on the project can be found in the May 2022 Issue of Modern Steel

Space Needle Floating Spiral Staircase

Curved Steel Spiral Staircase at the Space Needle in Seattle

Steel Spiral Staircase at the Space Needle in Seattle

Space Needle Seattle, Washington





Newly Renovated Restoration Hardware Retail Store Features Gorgeous Spiral Staircase
Newly Renovated Restoration Hardware Retail Store Features Gorgeous Spiral Staircase

Restoration Hardware’s newest San Francisco gallery spans all 5 stories of the historic and newly renovated Bethlehem Steel Building and features a gorgeous spiral staircase! You can visit the Bethlehem Steel Building on the corner of Illinois and 20th Street in the Dogpatch. Materials Albina rolled for the spiral staircase included:

20 lengths x 20 ft 1½" OD X .120" WALL HREW
4 pcs spiraled to a 8’-11” radius
4 pcs spiraled to a 4’-5” radius
4 pcs spiraled to a 8’-9” radius
1 pc bent flat to a 4’-5” radius
1 pc bent flat to a 8’-9” radius
1 pc bent to a 10” radius
6 lengths x 20 ft FB ½" X 2" A36
All material was rolled flat to a recalculated radius- customer to pull to pitch.
6 pcs bent to a 4’-1” radius the hardway
20 pcs bent to a 9’-0” radius the hardway
6 lengths x 20 ft C2 X 1 X .188 A36
All material was rolled flat to a recalculated radius- customer to pull to pitch.
6 pcs bent to a 4’-1” radius the hardway
10 pcs bent to a 9’-5” radius the hardway
144 pcs PL ¼" X 1'-2½" A572-50
24 pcs PL ¼" X 2'-4" A572-50
C15 X 33.9# A36
4 pcs bent to a 4’-3” radius the flanges in
5 pcs bent to a 8’-11” radius the flanges out
C12 X 20.7# A36
4 pcs bent to various radii the flanges in
2 pcs bent to various radii the flanges out

Spiral Staircase at Restoration Hardware Pier 70 San Francisco

Spiral Staircase at Restoration Hardware Pier 70 Bethlehem Steel Building

The Buddy Holly Hall of Performing Arts and Sciences is a 2022 IDEAS2 National Award Winner!
The Buddy Holly Hall of Performing Arts and Sciences is a 2022 IDEAS2 National Award Winner!

The Buddy Holly Hall of Performing Arts and Science in Lubbock, Texas is a 220,000 square foot state-of-the-art campus featuring two theaters, event space, a full-service bistro and a ballet academy under one roof. Albina bent various materials for the signature spiral staircase in the Christine DeVitt Lobby. See the video below to get a sneak peek inside!



The projects is featured in the May edition of Modern Steel Construction. For more details on the entire project and to see a full list of winners check out AISC's website



TS 16" X 8" X .625" WALL A500 GR C
16 pcs: Spiral bend the easy way
Bent down to a 7 ft plan view radius.



TS 10" X 6" X .625" WALL A500 GR C
10 pcs: Spiral bend the hard way
Bend down to a 14' 11" plan view radius.





Steel Spiral Stringers for The Buddy Holly Hall of Arts & Sciences



Top Down view of the Steel Spiral Staircase at The Buddy Holly Hall of Arts & Sciences





Steel Tree-Like Columns and Curved “Steel” Branches Create a Biophilic-Inspired Archway Entrance for the Freyer-Newman Center at the Denver Botanical Gardens
Steel Tree-Like Columns and Curved “Steel” Branches Create a Biophilic-Inspired Archway Entrance for the Freyer-Newman Center at the Denver Botanical Gardens

Albina bent 40,000# of steel for the steel tree-like columns and curved “steel” branches that create the biophilic-inspired archway entrance for the Freyer-Newman Center at the Denver Botanical Gardens. Albina bent 60 pieces of W8 X 31# A992 the hard way to a full scale layout. We also bent Tube Steel 8" X 6" X .500" WALL A500 GR B the hard way and MC8 X 20# A36 the hard way. The Freyer - Newman Center is a LEED GOLD building, designed by Denver’s Davis Partnership Architects. The Center houses six classrooms; four galleries; new herbaria for vascular plants, mushrooms and slime molds; laboratories; a new library and a coffee shop. Steel Tree-Like Columns and Curved Steel Branches for the Freyer-Newman Center at the Denver Botanical Gardens

The project was featured in the April Issue of Modern Steel.

Steel tree-like columns and curved steel branches for the Freyer-Newman Center at the Denver Botanical Gardens

"Bird of Paradise" on Display at Carrollwood Village Park in Tampa, Florida
"Bird of Paradise" on Display at Carrollwood Village Park in Tampa, Florida

"Bird of Paradise", a curved steel sculpture is located at Carrollwood Village Park in Tampa, Florida.

Artist @curt_pittman (www.curtpittman.net)


Materials bent by Albina included:
5 lens x 21 ft: 3" SCH80 A53B ERW. All material rolled by Albina to various radii, arc lengths and configurations.

2 lengths: 4" SCH80 A53B ERW. All material rolled by Albina to various radii, arc lengths and configurations.

2 lens x 20 ft: 1¼" X 1¼" X 1/8" ANGLE A36. All material rolled leg out by Albina to various radii, arc lengths and configurations.

Photo Credit: @curt_pittman

"Bird of Paradise" Raw Materials in Shop at Albina Co., Inc.

"Bird of Paradise" Assembly Prior to Installation at Carrollwood Village Park

"Bird of Paradise" Night Picture at Carrollwood Village Park in Tampa Florida

Curved Steel Artwork Takes Center Court at Louisiana Tech's Business School
Curved Steel Artwork Takes Center Court at Louisiana Tech's Business School

Displayed in the courtyard of Louisiana Tech's Business School, "Aspire" creates a unique piece of curved steel artwork for the students to pass by on the daily and imagine the person they aspire to be. Artist @curt_pittman (www.curtpittman.net)

Material bent by Albina included:
27 lens x 40 ft: 3" SCH80 A53B ERW. All material rolled by Albina to various radii, arc lengths and configurations.

90 lens x 16 ft: CH 1" X 1" X 1/8" 6063-T52 ALUM. All material rolled flanges out by Albina to various radii, arc lengths and configurations.

11 lengths: 2" SCH40 A53B ERW. All material rolled by Albina to various radii, arc lengths and configurations.

Photo Credit: @curt_pittman

"Aspire" by Curtis Pittman LA Tech University

Louisiana Tech University Business School "Aspire"

"Aspire" Business School Curved Steel Sculpture at LA Tech

"Aspire" Curved Steel Sculpture at LA Tech Business School

Curved Steel Canopies Create Gathering Place at Civic Square in Goodyear, Arizona
Curved Steel Canopies Create Gathering Place at Civic Square in Goodyear, Arizona

Civic Square, in Goodyear, Arizona, will serve as a highly-desirable community gathering spot for festivals, concerts, parades and other community events. Albina bent various materials for the canopies at the center of Civic Square. Albina bent the following materials for the project:

TS 16" X 8" X .375" WALL A500 GR B
16 pcs all bent the easy way to a 36 ft – 44 ft radii.

TS 14" X 6" X .375" WALL A500 GR B
12 pcs all bent the easy way to a 40 ft – 43 ft radii.

TS 10" X 4" X .250" WALL A500 GR B
5 pcs all bent the easy way to a 27 ft – 30 ft radii.

TS 6" X 3" X .375" WALL A500 GR B
4 pcs all bent the easy way to a 36 ft – 44 ft radii.

1½" SCH40 A500 GR B
21 pcs all bent to a 28 ft – 44 ft radii.

Civic Square Curved Steel Canopy Raw Material located in Goodyear, Arizona

Civic Square Curved Steel Canopies in Goodyear, Arizona
