Blog posts tagged with 'Beam Bending'

Curved Steel Facades Add Modern Touch to Newly Redesigned Bridgeport Village Outdoor Mall
Curved Steel Facades Add Modern Touch to Newly Redesigned Bridgeport Village Outdoor Mall

Bridgeport Village, an upscale outdoor mall in Tigard, Oregon recently underwent a $35 million dollar modernization and now features covered seating areas, a central courtyard area with new landscaping, a performance stage, updated building facades and about 20 new storefronts. Albina Co., Inc. was instrumental in helping the developers update the storefronts and bent various materials including:


2 lengths x 40 ft: W10 X 22# A992
Albina to roll all possible from each length (the easy way) to a 40’-4” centerline radius.

4 pcs of 3” X 3” X ¼” ANGLE A36
Albina to roll all possible from each length (leg in) to a 42’-7” outside radius.

3 lengths x 20 ft: 3” X 2” X ¼” ANGLE A36
Albina to roll all possible from each length (3” Leg in) to a 59’-1” outside radius.

3 lengths x 20 ft: 6” X 4” X 5/16” ANGLE A36
Albina to roll all possible from each length (4” Leg in) to a 59’-1” outside radius.

5 lengths x 20 ft: C10 X 20# A36
Albina to roll all possible from each length (flanges out) to radii ranging from 52’-7” – 59’-1”.

3 lengths x 20 ft: 3” X 2” X ¼” ANGLE A36
Albina to roll all possible from each length (2” Leg in) to a 58’-11” outside radius.

2 lengths x 20 ft: 3” X 3” X ¼” ANGLE A36
Albina to roll all possible from each length (Leg out) to a 52’-7” inside radius.

Bridgeport Village Curved Steel Storefront

Bridgeport Village Curved Steel Storefront

Bridgeport Village Curved Steel Storefront

Steel Tree-Like Columns and Curved “Steel” Branches Create a Biophilic-Inspired Archway Entrance for the Freyer-Newman Center at the Denver Botanical Gardens
Steel Tree-Like Columns and Curved “Steel” Branches Create a Biophilic-Inspired Archway Entrance for the Freyer-Newman Center at the Denver Botanical Gardens

Albina bent 40,000# of steel for the steel tree-like columns and curved “steel” branches that create the biophilic-inspired archway entrance for the Freyer-Newman Center at the Denver Botanical Gardens. Albina bent 60 pieces of W8 X 31# A992 the hard way to a full scale layout. We also bent Tube Steel 8" X 6" X .500" WALL A500 GR B the hard way and MC8 X 20# A36 the hard way. The Freyer - Newman Center is a LEED GOLD building, designed by Denver’s Davis Partnership Architects. The Center houses six classrooms; four galleries; new herbaria for vascular plants, mushrooms and slime molds; laboratories; a new library and a coffee shop. Steel Tree-Like Columns and Curved Steel Branches for the Freyer-Newman Center at the Denver Botanical Gardens

The project was featured in the April Issue of Modern Steel.

Steel tree-like columns and curved steel branches for the Freyer-Newman Center at the Denver Botanical Gardens

Curved Steel Roof at the UCHealth Steadman Hawkins Clinic in Denver Graces the Cover of Modern Steel
Curved Steel Roof at the UCHealth Steadman Hawkins Clinic in Denver Graces the Cover of Modern Steel

Albina Co., Inc. recently provided 102,000# of bent steel for the curved roof structure at the UCHealth Steadman Hawkins Clinic Denver in Englewood, Colorado. The building will serve as a rehabilitation and sports medicine center in Denver. The project's most prominant feature is the 185-ft-long, 40-ft-wide curved steel roof. The project is featured on the cover and as a feature article in of the February Issue of Modern Steel.

Curved Steel Roof UCHealth Steadman Hawkins Clinic Denver

Albina provided the following materials for the project:

W30 X 99# A992- 2 pcs bent to a 401 ft radius the hardway

W21 X 44# A992- 2 pcs bent to a 401 ft radius the hardway

W16 X 26# A992- 36 pcs bent to a 401 ft radius the hardway

W16 X 31# A992- 2 pcs bent to a 401 ft radius the hardway

C10 X 20# A36- 2 pcs bent to a 66’-5” radius with flanges in

C10 X 20# A36- 2 pcs bent to a 51’-7” radius with flanges out

C12 X 20.7# A36- 12 pcs bent to a 401 ft radius the hardway

Albina Co., Inc. Virtual & Aerial Tour 2020
Albina Co., Inc. Virtual & Aerial Tour 2020

Take a journey in, above and around our production shop and office with this high resolution virtual and aerial tour of Albina Co, Inc. See our state of the art roll bending machines in action from a plan view, soar through our bays, watch our certified welders in action, and take a peek into our office and newly renovated lunch and conference rooms.

Curved Steel at our Nation's Schools & Universities
Curved Steel at our Nation's Schools & Universities

Boy how the tide has turned! No longer do I hear, “I don’t want to go to school today!” Instead I hear, “I can’t wait until we get to go back to school!” Kids across the country are gaining a new appreciation for how important it is to physically be able to enter their school buildings to learn. We have been very fortunate to be involved in a number of projects at schools across the nation including custom spiral and circular staircases, curved steel signs, curved steel artwork, curved steel canopies, and more!

Todays Highlight: Curved Steel at our Nation’s Schools & Universities

Fariborz Maseeh College of Engineering & Computer Science at Portland State Curved Steel Artwork Portland, OR
Fariborz Maseeh College of Engineering & Computer Science at Portland State Curved Steel Artwork Portland, OR

Thomas Jefferson School of Law Curved Steel Spiral Staircase San Diego, CA
Thomas Jefferson School of Law Curved Steel Spiral Staircase San Diego, CA

UCSF Medical Center Curved Steel Parking Canopy San Francisco, CA
UCSF Medical Center Curved Steel Parking Canopy San Francisco, CA

University of Oregon Curved Steel Sky Bridge Phil & Penny Knight Campus for Accelerating Scientific Impact Eugene, OR
University of Oregon Curved Steel Sky Bridge Phil & Penny Knight Campus for Accelerating Scientific Impact Eugene, OR

Evergreen High School Curved Steel Sign Vancouver, WA
Evergreen High School Curved Steel Sign Vancouver, WA

Sherwood High School Bike Racks Sherwood, OR
Sherwood High School Bike Racks Sherwood, OR

Rainier Beach High School Curved Steel Handrail Seattle, WA
Rainier Beach High School Curved Steel Handrail Seattle, WA

Gonzaga University Curved Steel Spiral Staircase in the Student Union Spokane, WA
Gonzaga University Curved Steel Spiral Staircase in the Student Union Spokane, WA

Oregon State Student Experience Center Curved Steel Canopy Corvallis, OR
Oregon State Student Experience Center Curved Steel Canopy Corvallis, OR
Sometimes the Building Itself is Just As Interesting As What's Inside
Sometimes the Building Itself is Just As Interesting As What's Inside

Often times when you visit a museum, you are looking at the objects of historical, scientific, artistic or cultural significance on the inside of the building, but the BUILDING ITSELF is often very eye-catching, interesting and artistic as well! The same can hold true for your local amphitheater. Yes, you are there to focus on the band or production occurring under the amphitheater’s structure, but take a moment to also appreciate the structure itself.

Today’s Highlight: Museums & Amphitheaters

Dale Chihuly Garden and Glass Museum Curved Roof Structure Seattle, WA.
Dale Chihuly Garden and Glass Museum Curved Roof Structure Seattle, WA.

Sun Valley Music Pavilion Curved Roof Structure Sun Valley, ID.
Sun Valley Music Pavilion Curved Roof Structure Sun Valley, ID.

Peterson Auto Museum Curved Steel Supports for the "Skin" of the Building Los Angeles, CA.
Peterson Auto Museum Curved Steel Supports for the metal "Skin" of the Building Los Angeles, CA. (Photo Courtey A. Zahner)

UC Davis Manetti Shrem Museum of Art Curved Steel Canopies Davis, CA.
UC Davis Manetti Shrem Museum of Art Curved Steel Canopies Davis, CA.
Centennial Park Amphitheater Curved Steel Roof Structures Centennial, CO.
Centennial Park Amphitheater Curved Steel Roof Structures Centennial, CO.

Experience Music Project Curved Steel Supports for the metal "Skin" of the Building Seattle, WA.
Experience Music Project Curved Steel Supports for the metal "Skin" of the Building Seattle, WA.
Curved Steel Helps Create Unique Entry for the Eli Lilly San Diego Biotech Research Center in La Jolla, CA.
Curved Steel Helps Create Unique Entry for the Eli Lilly San Diego Biotech Research Center in La Jolla, CA.

Albina provided 109,000# of bent steel for the Eli Lilly San Diego Biotech Center in La Jolla, CA. Eli Lilly doubled the size of its research facility to 300,000 square feet during this project. Materials included: 8″ X 8″ X 5/8″ ANGLE A36- half of the parts rolled leg in and half of the parts rolled leg out. Tube Steel 8″ X 8″ X .500″ WALL A500 GR B 8 5/8″ OD X .625″ WALL A500B Wide Flange W16 X 57# A992- Split into WT8 and rolled some parts stem in and rolled some parts stem out. Wide Flange W24 X 103# A992- DOUBLE split to a finished height of 8¼” tall. Albina then rolled some parts stem in and other stem out.

Exterior Images of Curved Steel at The Madison Center "Great Room" in Seattle, Washington
Exterior Images of Curved Steel at The Madison Center "Great Room" in Seattle, Washington

We were in Seattle this weekend and were able to get some exterior pictures of The Madison Center. The Madison Center is a 530 foot tall, 36 story high rise office building in Seattle, Washington and is featured in the June edition of Modern Steel. Albina Co., Inc. was the bender/roller on this project and worked specifically on what is being called "The Great Room" which is a 45-foot tall steel framed entryway rotunda. Albina bent many material types for this project including tube steel 8" x 6" up to 12" x 12", 3" x 3" angle, W10 and W16 wide flange, 8" pipe and more. Check out the article for some more details on the architectural feat and some great pictures. We will be heading back up to Seattle next week to get some interior shots. Stay tuned!

Curved Steel Roof Structure at the Madison Center Seattle, WA.
Exterior Picture of The Madison Center Great Room

Madison Center Great Room Curved Tube Steel Roof Structure
The Great Room Rotunda

Curved Steel Wide Flange Roof Structure at the Madison Center Seattle, WA.
Close up of Curved Steel Wide Flange, Tube Steel and Pipe

Steel Spiral Staircase in the Great Room at the Madison Center
Curved Steel Spiral Staircase
Happy Father's Day

I'm proud of my hard work. Working hard won't always lead to the exact things we desire. There are many things I've wanted that I haven't always gotten. But, I have a great satisfaction in the blessings from my mother and father, who instilled a great work ethic in me both personally and professionally. -Tamron Hall

Father's Day is upon us! Father's Day is particularly important to me as I lost my father, Bill, over 8 years ago, and there isn't a day that goes by that I don't think about him or get a reminder of him while at work. It can be a phone call from someone in the industry who used to work with him, it can be an old quote I see come across my desk with his name on it, it can be my daily rounds through the shop where I can still see him problem solving with a machine operator on a particularly challenging job. Whatever it may be, I always remind myself that I am a representative of the Smith Family and the steel bending business that my grandfather and father helped to build. Jaime and I have been building on their values for many, many years now and feel great about where we have been able to take the business. All three generations have worked in both the shop and office during our careers. A fourth generation spends their summers pulling weeds, washing windows and doing database entry in their spare time. We have four generations of family who believe in the steel industry and believe in the value of hard work. I have no idea if my son and daughter will be interested in taking over the family business some day, but if they do, I am confident that they will work hard, be honest and carry on the traditions we have lived by for the last 80 years! I am a proud business owner and a proud Father. Happy Father's Day to all you Father's out there!

Bill & Brian Smith-2001
